TF Series

ORDER CODE: TY-TF

The Tyworth TF series takes display technology to the next level with its remarkable curved LED screens, which offer an immersive and dynamic viewing experience. This curvature capability allows the TF series to conform to various architectural spaces and design requirements

Dynamic Canvases

Ensuring that every detail is rendered with stunning clarity and impact. Its flexibility in installation and adaptability to different environments make it a versatile choice for creating memorable and impactful visual experiences.

Curve your world

The Tyworth TF series stands out with its innovative ability to curve, offering a transformative viewing experience. This unique feature allows for the creation of curved LED displays that enhance depth and immersion, making it ideal for environments where dynamic and engaging visuals are crucial.

Create something special

Imagine stepping into a space where the display seems to envelop you, drawing you into a world of vivid colors and sharp details. The TF series brings this vision to life by seamlessly curving around corners and contours, transforming flat surfaces into dynamic, three-dimensional canvases.

Download The Brochure

It’s all in the detail.
Take a closer look into the TF Series by downloading the brochure Here

LED Type
Application
Pixel Pitch（mm）
Module Resolution（W×H）
Size（mm）
Resolution（W×H）
Pixel Density（Dots/m²）
Material
Weight（kg)
Brightness
Viewing Angle (H/V)
Contrast Ratio
Power Consumption(Max.W/㎡)
Power Consumption (Average.W/㎡)
Scan Mode
Refresh Rate（Hz)
Gray Scale
Working Temperature
Working Humidity
Maintenance Method
IP Grade

TF-261

  • SMD1415
  • Indoor
  • 2.604
  • 96*96
  • 500*500
  • 192*192
  • 147456
  • Die cast aluminum
  • 7
  • ≥800
  • 140°/140°
  • 5000:1
  • 520
  • 173
  • 1/24S
  • ≥3840
  • 14
  • -10℃~+40℃
  • 10%-90%RH
  • Front and Rear
  • IP40/IP21

TF-291

  • SMD2020
  • Indoor
  • 2.976
  • 84*84
  • 500*500
  • 168*168
  • 112896
  • Die cast aluminum
  • 7
  • ≥800
  • 140°/140°
  • 5000:1
  • 530
  • 176
  • 1/21S
  • ≥3840
  • 14
  • -10℃~+40℃
  • 10%-90%RH
  • Front and Rear
  • IP40/IP21

TF-391

  • SMD2020
  • Indoor
  • 3.906
  • 64*128
  • 500*500/500*1000
  • 128*128/128*256
  • 65536
  • Die cast aluminum
  • 7/10
  • ≥800
  • 140°/140°
  • 5000:1
  • 530
  • 176
  • 1/16S
  • ≥3840
  • 14
  • -10℃~+40℃
  • 10%-90%RH
  • Front and Rear
  • IP40/IP21

TF-290

  • SMD1415
  • Outdoor
  • 2.976
  • 84*168
  • 500*500/500*1000
  • 168*168/168*336
  • 112896
  • Die cast aluminum
  • 7.5/11.5
  • ≥4500
  • 140°/140°
  • 4000:1
  • 800
  • 267
  • 1/17S
  • ≥3840
  • 14
  • -10℃~+40℃
  • 10%-90%RH
  • Front and Rear
  • IP65/IP54

TF-390

  • SMD1820
  • Outdoor
  • 3.906
  • 64*128
  • 500*500/500*1000
  • 128*128/128*256
  • 65536
  • Die cast aluminum
  • 7.5/11.5
  • ≥4500
  • 140°/140°
  • 4000:1
  • 800
  • 267
  • 1/16S
  • ≥3840
  • 14
  • -10℃~+40℃
  • 10%-90%RH
  • Front and Rear
  • IP65/IP54

TF-480

  • SMD1820
  • Outdoor
  • 4.8
  • 52*104
  • 500*500/500*1000
  • 104*104/104*208
  • 43264
  • Die cast aluminum
  • 7.5/11.5
  • ≥4500
  • 140°/140°
  • 4000:1
  • 800
  • 267
  • 1/13S
  • ≥3840
  • 14
  • -10℃~+40℃
  • 10%-90%RH
  • Front and Rear
  • IP65/IP54
